Airgency

AIRGENCY is an automatic actuation system to operate Bag-Valve-Mask (BVM) ventilation, also known as manual resuscitator, to ease the burden of medical workers in emergency conditions. Indications for AIRGENCY and BVM devices include respiratory failure (failure of ventilation, oxygenation, or both) and intubation failure.

Category:

Product Benefits : airgency operates to help patients achieve the desired respiratory parameters.

Product Advantages: airgency is a device that works by means of an air bag (bag) which is pressed by two claws (clamp) automatically controlled carefully, so as to achieve the pressure, tidal volume and I / E ratio of ventilation needed by the patient.

Usage Information: –

  • Open the top cover of the airgency device.
  • Attach the Ambu-Bag between the airgency pressure arms.
  • Connect the oxygen hose to the Ambu-Bag.
  • Connect the reservoir to the Ambu-Bag
  • Connect the inspiration breathing circuit to the Ambu-Bag.
  • Connect the pressure sensor hose and pressure release system control cable.
  • Fill the PEEP bottle with water according to the dosage for 5 cmH2O.
  • Install the PEEP bottle on the bottle holder so that it does not spill.
  • Connect the expiration breathing circuit from the PEEP bottle to the expiration valve.
  • Close the top cover of the Airgency device to lock the Ambu-Bag in position.
  • Connect the adapter cable connected to the power source to the power supply port.
  • Turn on the device according to the procedure for turning on the Airgency.
  • Attach the expiration breathing circuit to the PEEP bottle
  • Set the breathing parameters as desired.
  • Attach the breathing circuit to the patient in accordance with applicable medical procedures.

If the device is to be moved or moved with the patient, unplug the adapter cable from the power supply port. The AIRGENCY device will continue to run on battery power.

Production Company : PT Melf Global Mandiri

Material Specifications : –

airgency Emergency Automatic Resuscitator

  • Dimensions 22 x 24 x 37 cm
  • Weight < 5000 gr
  • Tidal Volume settings 300, 400, 500 mL
  • I/E Ratio settings 1:1, 1:2, 1:3
  • Breath Rate Settings 10, 15, 20 BPM
  • Operation Mode Settings Normal Mode & Assisted Mode
  • Correction Factor
  • Tidal Volume 300 mL +49 mL
  • 400 mL +64 mL
    • 500 mL +79 mL
    • Respiration Rate 10 BPM +1.5
    • 15 BPM +2.25
    • 20 BPM +3
    • I:E Ratio 1:1 +0.2
    • 1:2 +0.4

KEMENKES Medical Device Classification

Product Type Powered Emergency Ventilator Risk Class 2.C Category Anesthesia Equipment Subcategory Therapeutic Anesthesia Equipment Test Pass No. BPFK KEMENKES MK-UPK/BPFKJ/60/RSCOF/0 Power Supply Battery specification 5200 mAh Battery life 2 hours External power supply (input) 200 – 240 VAC 50/60Hz External power supply (output) 11 VDC 33 A

Dimensions/Size : 22 x 24 x 37 Cm
